Resources

Our resource library contains PDF files with information on our products available to you.
If you need more information or a special product manual please do not hesitate to contact us at 563.568.6387.

General

Automation
General

We're in CONTROL automation systems for trouble-free drum mix plant control and simple plant operation.

Download File
Total System Control
General

SYSTEMS' TSC is a Windows-based plant control program used to start, stop, and monitor motors used in plant operation, as well as to manually load from silos. TSC is designed for universal plant use, regardless of motors used and their functions.

Download File
ADP-GUI Windows-Based Drum Mix Control
General

We're in CONTROL ADP-GUI (Graphical User Interface) Windows-Based Asphalt Drum Mix Control.

Download File
Asphalt Pump Skid
General

Model APS-xxx Asphalt Pump Skid

Download File
WIN-LC3000
General

Designed to accurately control truck loading, print delivery tickets, store delivery data, and print operational reports.

Download File
Conveyor Scale & Feeder
General

We're in CONTROL conveyor scale & feeder components information.

Download File

Product Details

TSC Total System Control
Product Details

TSC is a plant control system to start, stop, and monitor motors used in plant operation, as well as to manually load from silos, and was designed for universal use for any plant regardless of motors used and their functions.

Download File
Model ADP100 Graphical User Package (GUI)
Product Details

Designed to provide a user friendly, graphically-enhanced user interface for the Asphalt Drum Mix Control System. Connects to the ADP-100 with a single high speed serial cable.

Designed to proportion aggregates and additives according to prescribed mix design formulas, and to measure and control the liquid asphalt mass flow rate, so the blends are accurately interlocked to the measured aggregate flow.

Download File
Model ADP100 SEC Agent Enterprise Data Package
Product Details

All of SYSTEMS Windows based control products are capable of logging critical business data. SEC Agent is a small application running in the background that handles data synchronization of data to a central server.

Download File
Model ADP-020B Asphalt Drum Mix Process Controller
Product Details

Designed to measure and control the liquid asphalt flow rate so the asphalt blend is accurately interlocked to the measured aggregate flow. Interface modules are available that allow this controller to be configured on-site, to include virgin and recycle belt scales, asphalt and mix temperatures, style of asphalt control and 0 to 5 simple potentiometrically controlled feeders.

Download File
Model WIN-LC3000 Silo Loadout System
Product Details

Designed to accurately control truck loading, print delivery tickets, store delivery data, and print operational reports. NTEP Certified. Provided with an industrial grade, fanless PC, along with a PLC hardware interface. Using a PC separately from any process automation provides the user flexibility in the choice of process control components and subsequent system upgrades.

Download File
Model WIN-LC3000 Add-on Features
Product Details
  1. License Plate Photo Capture
  2. Signature Pad
  3. Material Temperature Capture (Shipped Loose)
  4. Material Temperature Capture (With Enclosure for PLC and Modules)
  5. Temperature Probe Assembly
  6. Loading Traffic Light Director
  7. High-Intensity Scoreboard Display
  8. Remote Receipt Printer
Download File
WIN-LC-PLT-EDIT - Plant Editor Data Transfer Software
Product Details

Designed to efficiently allow company accounting departments to electronically transfer ticket information from multiple SYSTEMS’ Model WIN-LC3000 Loadout plant locations to a central computer via the Internet.

Download File
Model LC-1000 Multiple Silo Loadout Automation
Product Details

Designed to accurately control truck loading from one or more asphalt silos with one or more scales, print delivery tickets, store delivery data, and print operational reports.

Download File
Model LC-2000 Single Silo Loadout Automation
Product Details

Designed to accurately control truck loading from a single silo, print delivery tickets, store delivery data, and print operational reports.

Download File
DOS to WIN LC3000 Conversion
Product Details

Silo Loadout Upgrade for existing DOS-Based systems.

Download File
Model RedRover v3 Loadout Data Transfer Software
Product Details

MS Windows® OS software designed to allow plant data to be exported and transferred to another location from SYSTEMS’ DOS-based Loadout computer.

Download File
Model AM-1600 Multiple Ammeter Display
Product Details

Designed as a multiple ammeter display in a form that allows a quick overview of selected plant motor loads. Provides an accurate indication of actual loads and visual and audible alarms of both overload and underload conditions. Displays incoming or generated power voltage and frequency from up to two sources.

Download File
