SILO LOADOUT SYSTEM
Click image for larger view
Loadout Add-Ons
WinLC3000 Add-on Features
Automation
WIN-LC3000.15 | License Plate Photo CaptureProvides proof of transaction by shooting a time-and date-stamped photo of truck license plateand storing it in the loadout system database.
- Industrial 2-megapixel network bullet camera for outdoor surveillance.
- Auto-iris capability protects the lens from damage induced by direct sunlight.
- Furnished with removable IR-cut filter and IR illuminators for superior image quality, day and night.
- IP67-rated housing protects against rain and dust to ensure reliable operation in all weather conditions.
- Equipped with a mounting bracket that conceals all cables within the bracket to prevent vandalism.
292N | Material Temperature Capture
(Shipped Loose)
Non-contact infrared temperature measurement at time of load provides a tool to determine when burner temps should be adjusted to assure that asphalt is application-ready when it is delivered.Also provides documentation for state inspectors that mix meets project specific requirements.
- Includes PLC, Analog Module, Ethernet Module, and one Temperature Probe Assembly for one silo.
- Infrared probe assembly measures approx. 4 1/2”h x 3”w x 3”d.
- Additional silo(s) require purchase of additional 1293 Infrared Temperature Probe(s)
- For each probe assembly, customer must supply necessary length of 2-conductor, 18 ga. Shielded Belden cable for a 4-20 mA signal.
1292 | Material Temperature Capture
(With Enclosure for PLC and Modules)
- Includes PLC, Analog Module, and Ethernet Module housed in 15” x 25” x 8-3/4” enclosure. Also includes a Temperature Probe Assembly for one silo.
- Infrared probe assembly measures approx. 4 1/2”h x 3”w x 3”d.
- Additional silo(s) require purchase of additional 1293 Infrared Temperature Probe(s)
- For each probe assembly, customer must supply necessary length of 2-conductor, 18 ga. Shielded Belden cable for a 4-20 mA signal.
1293 | Temperature Probe Assembly
- Includes on Temperature Probe Assembly for one silo. One assembly is included with 1292 or 1292E. Add’l assemblies must be purchased – one per silo – for systems of two silos or more.
- Infrared probe assembly measures approx. 4 1/2”h x 3”w x 3”d.
- For each probe assembly, customer must supply necessary length of 2-conductor, 18 ga. Shielded Belden cable for a 4-20 mA signal.
WIN-LC3000.50 | Loading Traffic Light Director
Helps ensure trucks will be correctly positionedbeneath silo and have a clear signal when load is
complete. Keeps traffic flow efficient and steady.
- PLC that fires appropriate lane light at the end of the load based on commands sent from loadout computer.
PDF Document: WIN-LC3000 Add-on Features
